Minerva Digital Pattern 4248

Introducing a digital pattern for a clean-lined stand-collar coat – Minimal Structure with Subtle Volume.

WHEN TO WEAR DESIGN 4248

This midweight coat combines simplicity with presence. Its architectural funnel collar and structured silhouette make it suitable for a wide range of situations:

Midseason Chill: Layer it over slim trousers or a midi skirt for polished transitional outfits.
Creative Office Days: The coat’s minimal tailoring makes it ideal for elevated workwear with a distinctive edge.
Museum Visits & Cultural Events: The back box pleat offers just enough movement and ease for walking and standing.
Everyday Style: Its unadorned lines and soft A-line allow for versatile casual wear in structured fabrics.

KEY DESIGN FEATURES

Silhouette: Slight A-line shape with long vertical seams and no darts, offering subtle structure without constriction.
Collar: High stand collar shaped away from the neck for a crisp, sculptural frame.
Closure: Center front button closure for a clean, symmetrical look.
Sleeves: Two-piece set-in sleeves with gentle shaping.
Back Detail: Box pleat inserted into center back seam for ease and interest.
Length: Falls to just above the knee for a tailored outerwear finish.
Style: The perfect balance between structure and softness—precise, architectural, and quietly bold.

LEVEL OF DIFFICULTY

Intermediate. This coat requires precision in collar construction and sleeve assembly.

SEAM ALLOWANCES

No seam allowances by default. If an option to add them at 1 EUR is chosen, all seams are 1 cm. Hem allowance on sleeves and bottom: 3.5 cm. Pocket bag seams: 2 cm. Hem of lining: 2 cm.

Please note: a single contour on the pattern pieces means no seam allowances are included. A double contour indicates seam allowances are included.

FABRIC RECOMMENDATIONS FOR DIGITAL PATTERN 4248

Works best with medium to heavy fabrics with body and crispness. Ideal choices include:

Wool coating
Gabardine
Coated cotton
Dry-hand suiting blends

Avoid overly fluid or stretchy fabrics to maintain silhouette clarity.

ADDITIONAL SUPPLIES

Lining: Satin, viscose, polyester lining.
Fusible Interfacing: Recommended for collar, front facing, and patch pieces.
Additional Notions: Shoulder pads, 5 buttons.

CUTTER’S MUST FOR DIGITAL PATTERN 4248

From Main Fabric:

Upper back – 2 pieces

Back (cut on fold) – 1 piece

Upper front – 4 pieces

Front – 2 pieces

Front facing – 2 pieces

Upper sleeve – 2 pieces

Under sleeve – 2 pieces

Belt – 2 pieces

Upper collar – 1 piece

Under collar – 1 piece

Collar tab – 2 pieces

Bow (optional) – 1 piece

Belt loop – 1 piece

Welt – 2 pieces

Pocket bag (main) – 2 pieces

From Lining Fabric:

Pocket bag (lining) – 2 pieces

Back (cut on fold) – 1 piece

Front – 2 pieces

Upper sleeve – 2 pieces

Under sleeve – 2 pieces

Lining pieces are based on outer garment templates minus facings. Box pleat included in lining.

From Fusible Interfacing:

Apply to facings, welt, collar tab, bow, upper front, and front pieces as marked.

IMPORTANT INFORMATION

Before cutting your fabric:
• Print the pattern pieces and lay them out on your fabric width (90–150 cm) to determine fabric requirements.
• Account for mirrored and paired pieces.
• During assembly, pay attention to notches—they must align.

DIGITAL PATTERN 4248 FOR 3D DESIGNERS, CONTRACTORS, AND ADVANCED SEWISTS

DXF AAMA for 3D Designers: The DXF AAMA format ensures compatibility with most 3D fashion design software, enabling easy previews of how the dress will look and move on a digital mannequin. Designers can make adjustments quickly and accurately.
PLT Format for Contractors: Plotter-ready PLT format allows sewing contractors to create efficient layouts for accurate cutting and optimal material use, ideal for bulk production or custom orders.
PDF Format for Advanced Sewists: The user-friendly PDF format allows advanced sewing enthusiasts to print and assemble pattern pieces at home.

CUSTOM FIT OPTIONS WITH INDIVIDUAL MEASUREMENTS OR ASTM SIZES

Pattern 4248 offers both custom sizing based on individual measurements and ASTM US standard sizing.

Bust: 35 cm to 170 cm
Low Hip: 35 cm to 190 cm

The drafting software adjusts sleeve length, bust width, and coat length to your inputted data, minimizing alterations and ensuring optimal proportions.
